CHAPTER 6 PG-FP4 OPERATION IN STANDALONE MODE
6.1.5
[Utility/Misc.] menu
The [Utility/Misc.] menu is used to check the F/W version of the PG-FP4 and the version of the parameter file
downloaded. It is also used to execute RESET of the PG-FP4.
This menu cannot be used to change settings.
[Utility/Misc. >]
? Pressing the Next button displays the [Commands] menu.
? Pressing the Enter button displays the following commands that can be executed on the [Utility/Misc.] menu.
? Pressing the Cancel button displays the [Commands] menu.
[ Reset PG-FP4 > ]
↓ Next button
[ PG-FP4 F/W Version ]
When the Enter button is pressed next, the programmer is reset.
PG-FP4 F/W Version displays the firmware version number of the PG-FP4.
Display example
PG-FP4 F/W Version
V1.16
↓ Next button
[ PRM Name ]
PRM Name displays the file name of the parameter file stored in the PG-FP4.
Display example
PRM Name
70F3025A
↓ Next button
[ PRM File Version ]
↓ Next button
[ HEX File Name ]
PRM File Version displays the version of the parameter file stored in the PG-FP4.
HEX File Name displays the name of the downloaded file stored in the specified valid
memory area in the user program area of the PG-FP4.
It displays “n.a.” if the downloaded file is invalid.
The file name is displayed after either of the following steps are executed.
1. After downloading a user program into the user program area that is specified
as a single memory area, use the user program as two independent memory
areas (Area 0 and Area 1).
2. After downloading a user program into either Area 0 or Area 1, switch the valid
memory area to the other memory area.
↓ Next button
86
[ CRC Sum (PG-FP4) ]
CRC Sum (PG-FP4) calculates and displays the checksum value of the valid memory
area specified in the 2 MB user program area of the PG-FP4.
Display example
CRC Sum (PG-FP4)
6AEDF4F4
User ’s Manual U15260EJ4V0UM
